Bộ chuyển mạch quang 2x10/100/1000Base-TX + 8x1000Base-FX SFP. Model: G-UES-8GX2GT-SFP

Detail Specifications Other

G-NET G-UES-8GX2GT series unmanaged Gigabit Fiber Aggregation Switch provides 2x10/100/1000Base-TX RJ45 ports and 8x1000Base-FX Fiber ports,which can implement mutual conversion between 10Base-T/100Base-TX/1000Base-TX twisted pair electrical signal and 1000Base-FX optical signal.G-UES-8GX2GT-SC20 can extend the transmission distance of a network from 100m over copper wires to 20Km.This type of fiber converter supports two different types of network connection media types:10/100/1000Base-TX and 1000Base-FX.It also supports IEEE 802.3,IEEE 802.3ab,IEEE802.3z,IEEE802.3u,IEEE802.3x standard 10/100/1000M,full/half-duplex, and MDI/MDI-X auto negotiation,All ports support wire speed switch, jumbo frame tr ansmission.It is a reliable and economic choice for your security system,electronic power system and traffic system.

Features

▪Support 8x1000Base-FX Fiber Ports and 2x10/100/1000Base-TX RJ45 ports

▪Compliant with IEEE802.3,IEEE 802.3ab,IEEE 802.3z,IEEE802.3u,IEEE802.3x standard

▪Support store-and-forward forwading mode

▪Flow Control Type: Full duplex adopts IEEE 802.3x standard, half duplex adopts back pressure standard

▪Supports10/100/1000M full duplex and half duplex

▪Supports auto MDI / MDI-X,obtains the fastest possible connection

▪Supports MAC address auto learning and auto aging

▪LED indicators display the working status,supporting simple trouble shooting

▪All ports support wire speed switch

▪Plug and play, no configuration required

▪Desktop or Wall Mounted,easy to install and use

▪Fanless design,natural cooling

▪External Power Supply

Ordering Information
